Description
These BNC style electrode holders are compatible with Heka, List, NPI and Dagan patch clamps.
- Fits all headstages having BNC style connectors
- Made from polycarbonate for lower noise levels in patch clamp applications.
- Gold-plated connector pins, connector insulators made from Teflon® or polycarbonate.
- Holders attach directly to the headstage, are available with choice of straight (axial), right angle or 45° body.
Spécifications
| Wire/Hybrid | Body Style | Port | Glass OD (mm) | Model | Order No. | Image |
|---|---|---|---|---|---|---|
| Wire | Straight | No | 1.0 | QSW-B10N | 64-1109 |  |
| 1.2 | QSW-B12N | 64-1110 | ||||
| 1.5 | QSW-B15N | 64-1111 | ||||
| 1.7 | QSW-B17N | 64-0746 | ||||
| 2.0 | QSW-B20N | 64-1112 | ||||
| Yes | 1.0 | QSW-B10P | 64-0825 |  |
||
| 1.2 | QSW-B12P | 64-0826 | ||||
| 1.5 | QSW-B15P | 64-0827 | ||||
| 1.7 | QSW-B17P | 64-0979 | ||||
| 2.0 | QSW-B20P | 64-0828 | ||||
| 45° | No | 1.0 | Q45W-B10N | 64-0845 |  |
|
| 1.2 | Q45W-B12N | 64-0846 | ||||
| 1.5 | Q45W-B15N | 64-0847 | ||||
| 1.7 | Q45W-B17N | 64-1099 | ||||
| 2.0 | Q45W-B20N | 64-0848 | ||||
| Yes | 1.0 | Q45W-B10P | 64-1059 |  |
||
| 1.2 | Q45W-B12P | 64-1060 | ||||
| 1.5 | Q45W-B15P | 64-1061 | ||||
| 1.7 | Q45W-B17P | 64-0969 | ||||
| 2.0 | Q45W-B20P | 64-1062 | ||||
| 90° | No | 1.0 | QRW-B10N | 64-0865 |  |
|
| 1.2 | QRW-B12N | 64-0866 | ||||
| 1.5 | QRW-B15N | 64-0867 | ||||
| 1.7 | QRW-B17N | 64-1104 | ||||
| 2.0 | QRW-B20N | 64-0868 | ||||
| Yes | 1.0 | QRW-B10P | 64-1079 |  |
||
| 1.2 | QRW-B12P | 64-1080 | ||||
| 1.5 | QRW-B15P | 64-1081 | ||||
| 1.7 | QRW-B17P | 64-0974 | ||||
| 2.0 | QRW-B20P | 64-1082 | ||||
| Hybrid | Straight | No | 1.5 | QSH-B15N | 64-1357 |  |
| 1.7 | QSH-B17N | 64-1358 | ||||
| 2.0 | QSH-B20N | 64-1359 | ||||
| Yes | 1.5 | QSH-B15P | 64-1360 |  |
||
| 1.7 | QSH-B17P | 64-1361 | ||||
| 2.0 | QSH-B20P | 64-1362 |
